105 COUPE PARTS : BEARINGS & SEALS

Gear Lever pinch bolt. Suitable for all 105 & 115 series cars.

Small metal washer that sits on top of the gearbox top seal (available separately under code GB039) and is retained by the gear lever.

Small rubber gearbox seal. sits under the gear lever and on top of the metal plates on the rear 'tower' of the gearbox. Use in conjunction with the small washer available under code GB039/1.

OE quality Corteco brand front gearbox to bell housing oil seal to fit all 105 Series cars with hydraulic clutches.

Front gearbox to bellhousing oil seal - to fit cars with hydraulic clutches.

Front gearbox to bell housing oil seal to suit mechanical clutch 750/101/105 cars and all 2600 (which are hydraulic clutch). NOT suitable for early "split case" 750 gearbox.

Front gearbox to bell housing oil seal, to use a late hyradlic gearbox with an early cable clutch bell housing.

OE quality Corteco brand rear gearbox oil seal to fit all 105 Series gearboxes as well as all 5 speed 101 and 106 Series gearboxes.

Rear gearbox oil seal to suit all 105 series gearboxes, both mechanical/cable and hydraulic clutch cars, as well as 101 and 106 series gearboxes.

Internal gear bush for 1st to 4th gear on all 101/105 Series gearboxes. Also fits late 102 series and all 2600 (106 series). Outer Diameter - 36.5mm Inner Diameter - 34.8mm Depth - 28.8mm

Input shaft bearing to suit later style hydraulic clutch gearboxes, where the input shaft is retained by a large nut - not a circlip like earlier style gearboxes. Inside diameter 30mm, outside diameter 62mm, width 23.8mm. See GB004 for the input bearing...

Input shaft bearing to suit mechanical clutch cars (inc. 101 series) and early hydraulic clutch cars where the input shaft is retained by a circlip. Also fits late 102 series and all 2600 (106 series). Internal diameter 30mm, outside diameter 62mm, width...

Input shaft needle roller bearing to suit all 101 / 105 gearboxes. Also fits late 102 series and all 2600 (106 series). Inside diameter 21mm, OD 25.7mm, width 16.5mm.

Mainshaft front bearing to suit hydraulic clutch gearboxes. Inside diameter 30mm, outside diameter 62mm, width 23.8mm.

Mainshaft front bearing to suit mechanical 105 series clutch cars. Also fits 101 series, late 102 series and all 2600 (106 series). Internal diameter 30mm, outside diameter 62mm, width 23.8mm.

Gearbox mainshaft rear bearing to suit hydraulic clutch gearboxes. Inside diameter 25mm, outside diameter 52mm, width 15mm.

Mainshaft rear bearing to suit mechanical clutch cars. Inside diameter 25mm, outside diameter 52mm, width 15mm.

Layshaft front bearing (internal diameter 20 mm, OD 52 mm, width 22.2mm) to suit gearboxes with hydraulic clutches. Some early hydraulic clutch gearboxes use GB007 so please measure before ordering.

Layshaft front bearing (25mm inside diameter, OD 52mm, width 20.6mm) to suit mechanical clutch and some early hydraulic 105 series gearboxes. Also fits 101 series, late 102 series and all 2600 (106 series).

Layshaft middle bearing for 101 and 105 series gearboxes Also fits late 102 series and all 2600 (106 series).

Rear layshaft bearing (inside diameter 30mm, outside 62mm, width 16mm) to suit hydraulic clutch gearboxes.

Layshaft rear bearing to suit mechanical clutch 105 series cars. Also fits 5 speed 101 series, late 102 series and all 2600 (106 series). Outer diameter - 62mm Inner diameter - 30mm Thickness - 16mm

5th gear needle roller bearing. Also fits 101 series, late 102 series and all 2600 (106 series). Inside diameter approx 31mm, OD approx 34.7mm, width 26.5mm
