105 SPIDER PARTS : HANDBRAKE

The main handbrake cable from the handle to the pivot on the differential to fit all Spiders with ATE brakes 1967 to 1993. Also fits Junior Zagato.

Dunlop rear handbrake side cable, left side.

Dunlop rear handbrake side cable, right side.

Handbrake shoes Kit - Includes Side cables BR055 & BR056, , X2 short handbrake shoe spring BR094,  X2 long handbrake shoe spring BR095, X2 handbrake adjuster mechanism BR076,  X4 handbrake shoe retaining spring BR054, X4 handbrake shoe retaining pin...

BREMBO Handbrake shoes - set of 4 to suit all cars with ATE brake systems 1967 onwards. Fits inside in the 'brake drum' inside the rear brake disc. One set of 4 brake shoes per car.

Handbrake shoes - set of 4 to suit all cars with ATE brake systems 1967 onwards. Fits inside in the 'brake drum' inside the rear brake disc. One set of 4 brake shoes per car.

Clevis pin for the brake master cylinder, all cars with standing pedal. Pedals mounted on the floor. Diameter: 9.4mm Length: 30mm

Clevis pin for handbrake side cable. Used in conjuction with BR055 and BR056 Diameter: 8mm Length: 28.4mm

Handbrake side cable right

Left side handbrake cable (looking from the rear of the car). This goes from main cable end on the centre of the differential to the handbrake mechanism in the wheel.

Handbrake shoe retaining pin holder to fit the handbrake mechanism on most 105 series cars from around 1968. Size 13.5mm narrowest diameter X 18mm widest diameter x 6.7mm height.

Short handbrake shoe spring to fit all 105 Series cars with ATE braking systems. One used per side, two per car. See BR093 for the matching long spring.

Long handbrake shoe spring to fit all 105 Series cars with ATE brakes. One used per side, two per car. See BR094 for the matching short spring.

Handbrake lever assembly to fit the handbrake mechanism on ATE braked cars where the cable attaches to the handbrake mechanism.

Handbrake adjuster mechanism to fit the handbrake on all ATE braked system cars. Requires the 'sleeve' from your exisiting adjuster mechanism to work fully.

Rubber gaiter for the handbrake side cable where it connects to the backing plate of the rear brakes.

Handbrake shoe retaining spring for the pin that holds the shoes to the backing plate. One used per shoe, 4 used per car.

Handbrake shoe retaining pin to fit the handbrake mechanism on all ATE braked 105 Series cars. 1 used per brake shoe, 4 used per car.

Metal fork that screws to the front end of the handbrake cable where it attaches to the lever mechanism on all ATE braked 105 Series cars (and possibly Dunlop braked Sprint GTs & 1600 Roundtail Spiders as well).

Handbrake ratchet pawl end piece - bears against the rachet mechanism for the handbrake (available separately under code BR052).

Handbrake ratchet mechanism to fit all 105 Series cars. See also the pawl end piece that bears against the rachet under item code BR095.
