JUNIOR ZAGATO PARTS : CYLINDER HEAD

Woodruff key for 4 cylinder and V6 models.

Athesil RTV silicone sealant. A premium sealant/ gasket maker developed by Athena for professional use in engine maintainace and repair. The RTV (room temperature vulcanizing) silicone seals plastic metal componants, crankcases, manifolds ...

Oil filler cap seal

Oil filler cap -  metal bayonet style as fitted to most Nord twin-cam engines and 2600 models.

Exhaust manifold nut to suit 101, 105, 116 and 75 engines, including V6. 8 fitted per cylinder head. These are a smaller outer diameter than the original which makes tightening easier as you have more access room around the nut.

Exhaust/inlet manifold stud 34mm to suit all 4 cylinder 101, 105, 116 and 75 engines, including TS. There are 8 on the exhaust side and 7 on the inlet side, of which three are longer and not currently available.   Please measure your existing inlet studs...

GTA style oil filler cap with inbuilt breather  outlet suitable for venting to an oil catch tank.

Chromed cylinder head nut for 1300 & 1600 engines.

Cylinder head nut for 105, 1300 & 1600 engines.

Chromed cylinder head nut for 1750 & 2000 engines with larger head studs including TS.

Bolt for holding down the cam cover on all twin-cam 101, 105 and also 106 series cars. In the original style with the serrated edge and large allen key socket. 6 bolts per car. Black "rifle" finish.

Later style valve/cam cover hold down bolt with the large flats suitable for use with a 17mm spanner.  Fits 4 cyl 105, 116 and 75 engines.

Chromed bolt suitable for holding down the cam cover on all twin-cam 101 and 105 series cars. In the original style with the serrated edge and large allen key socket. 6 bolts per car.

Support bracket for the early style 'crossover' plenum. Please see pictures

Curved oil breather hose from the cam cover to the air filter canister on many of the 105 and 116 series cars. Note that this fits both the early style 'crossover' air-cleaner setups as well as the later tubular style air-cleaners.

Bracket fitted on top of cylinder head used to lift engine out, fitted to 101, 105, 116 and 75 engines (excluding TS and V6).

Set of six 'washers' (four fibre, two aluminium) for the cam/valve cover hold down bolts on all 101, 105, 116 and 75 engines (excluding Ts and V6). The same washers are also used on Montreal engines - please enquire in need. Note that the aluminium...

A pair of 'half moon' rubber seals for the back of the camshaft housing at the rear of the cylinder head on 4 cylinder 105, 116 and 75 engines.

Lower valve spring cup washer. To suit 4 cyl 101, 105, 116 and 75 engines including TS.

Set of standard valve springs to suit all 4 cylinder 101, 105, 116 and 75 engines, including TS.

Exhaust valve guide to suit all 4 cylinder 101, 105, 116 and 75 engines, plus Montreal - with 9mm valve stems. Not TS. Sold individually.

Inlet valve guide to fit all 4 cylinder 101, 105, 116 and 75 engines - plus Montreal - with 9mm valve stems. Not TS. Can also be used as an exhaust valve guide if you wish to fit valve stem seals on the exhaust valves.  Sold individually.

OE quality valve guide stem seal -  to fit the inlet valve guide on all 101, 105, 116 and 75 engines (including V6) with 9mm valves and valve guide stem seals. Goetze brand or similar. Also used on the inlet guide on Montreal engines. Not suitable for TS.

Valve shim to fit GTA, 750 Giulietta and 75 Twin Spark engines. They are available in increments of .025mm from 1.500 (.059")  to 3.500 mm (.138"). Please select size from the drop-down menu.
